Electricity Remains a Serious Workplace Hazard
Excerpt Courtesy of OH&S Publication
By Laura Proctor, Srin Kuchibotla
The body's reaction to electric shock can range from a minor tingling sensation to instant death. Even at levels as low as 3 milliamperes, current traveling through the body can cause indirect or secondary injuries, including bruising and bone fractures. A milliampere (mA) is a measurement of current, with 1,000 milliamperes per amp. For example, 120 volts/1000 Ώ is equal to .120 AMP, which is equal to 120 mA.
Consider how the body reacts when it comes into contact with the following levels of electricity:
0.5-3 mA
|
Tingling sensation
|
3-10 mA
|
Muscle contractions and pain
|
10-40 mA
|
"Let-go" threshold
|
30-75 mA
|
Respiratory paralysis
|
100-200 mA
|
Ventricular fibrillation
|
200-500 mA
|
Heart clamps tight
|
1500+ mA
|
Tissue and organs start to burn
|
To put these levels of exposure into perspective, the voltage levels for equipment and power sources present in many industrial facilities follow:
120V
|
Standard office wall voltage
|
240V
|
Heater circuits, small machinery, drill presses
|
277V
|
High-intensity overhead lighting circuits
|
480V
|
Heavy-duty machinery
|
600V
|
Mining machinery
|
13000-15000V
|
Incoming feed from the power company
|
