ColorMax 7 Digital Color Printer



The ColorMax 7 Digital Color

Printer uses the latest in inkjet technology to produce full-color output at three times the speed of traditional shuttle head printers, at one third the per-page cost. Its Memjet� print head has 70,400 ink nozzles and no moving parts, which offers higher speeds, lower ink and maintenance costs and less noise.



The ColorMax 7 produces
full-color CMYK output, up to 16.8 million colors, on a variety of paper stocks and sizes, with full-bleed capability on media up to 8.5" wide. It can print 1600 x 1600 dpi at 6 inches per second, and 1600 x 800 dpi at 12 inches per second.




With its thermal inkjet technology, it doesn't require heat or contact to create an image, so it can safely be used with pre-printed envelopes and windowed envelopes without damaging the window or marring the original image. High-capacity ink tanks and fully-automated print head cleaning ensure optimum print quality throughout print runs.




ColorMax7 Digital Color Printer
ColorMax7 Digital Color Printer




Specifications:

  • Speed, page printing: Up to 3,600 per hour
  • Speed, #10 envelopes: Up to 7,500 per hour
  • Duty Cycle: 30 million pieces or 500,000 per month over a 5-year life cycle
  • Material Size: Min: 3" W x 4.25" L Max: 9.5" W x 17" L
  • Material Thickness: Up to 1/48" (0.5 mm / 430 gsm / 160# cover / 240# index)
  • Print Quality: Up to 1600 x 1600 dpi @ 6 inches per second, up to 1600 x 800 dpi @ 12 ips
  • Print Area: Up to 8.5" x 17" with full bleed capability
  • Ink Tank Capacity: Cyan 250ml, Magenta 250ml, Yellow 250ml, Black 500ml
  • Color Matrix: Up to 16.8 million colors
  • Hardware Required: Windows-based PC, XP and newer
  • Java 6.0 or newer and Microsoft.NET Framework 3.5 must be installed on PC
  • PC Interface: USB & Ethernet
  • Firmware Update: Electronic firmware update downloads via PC connection
  • Fonts: All available TruType or Postscript system fonts
  • Dimensions: 24" L x 20" W x 18" H With conveyor stacker: 81" L x 20" W x 18" H
  • Weight: 90 lbs
  • Electrical: 100VAC 60Hz / 2A
  • High-speed color printing for a variety of media:
  • letterhead, invitations, postage and barcodes,
  • windowed/non-windowed envelopes, invoices
  • Full-color inkjet with Memjet�
  • thermal technology
  • Speeds of up to 7,500 #10 envelopes per hour
  • Fixed print head: a single 8.77" bar spanning the
  • width of the printing surface
  • Up to 1600 x 1600 dpi resolution
  • Full-bleed capability up to 8.5" wide
  • High capacity ink tanks; Cyan 250ml, Magenta
  • 250ml, Yellow 250ml, Black 500ml
  • Up to 16.8 million colors
  • Built-in top-load feeder
  • Pressure roller transport system with star rollers
  • TruType or Postscript system fonts
  • Automated print head maintenance system
  • USB and ethernet PC interface
  • Electronic firmware updates via PC connection
