Keeping It Safe

CORI-FLOW™ for hazardous batch ingredients

Polyvinyl alcohols are used as suspending agents in the polymerization reactions of Vinyl Chloride Monomer (VCM) to produce PVC.

To aid the development of these additives our customer needed a pilot reactor. The pilot plant was designed to be capable of being tuned to match the technology and production reaction characteristics of the full-scale PVC production units. A significant challenge included the containment of the toxic and flammable VCM raw material to deliver zero emissions to the environment.

The CORI FLOW™ with integrated PID control functions receives the input signals from the pilot plant control system, driving the electromagnetic coil of the control valve. The Coriolis sensor is metal sealed and there is no gland packing or external connection to the plunger of the control valve, which eliminates all potential VCM leak paths in this area. The microprocessor-based intelligence within the CORI-FLOW™ unit itself can be used for digital RS232 or fieldbus interface as well as computation and control.

Click here for more further information on the Coriolis solutions from Bronkhorst®.

PVD (Sputtering)

Superior Layer Uniformities for Thin Film Coatings

Glass coatings are made for modifying optical properties of glass, to improve solar transmission characteristics or just for changing its aesthetic appearance. Whether for solar and energetic control or architectural purposes only, glass coating is a very demanding process.

For attaining thin-film coatings compliant with the highest quality standards the process gas system must be capable of providing superior layer uniformities. Easy maintenance is also a major concern when large area coaters are involved. Bronkhorst fully understands the Glass Coating Industry's demands and has therefore developed sophisticated solutions specially addressed to meet the demands of state of the art large area glass coating applications.

Superior layer uniformity, high yields and reduced cost of ownership are among the demands of the Glass Coating Industry. By controlling individually process gas segments, film thickness uniformity improvements are achieved. Additionally, if the control is made by instruments capable of securing a stable flow profile, reproducibility and fast response time, optimal performance can be reached. In order to reduce the cost of ownership, instruments must be reliable and endure working 24 hours a day, 7 days a week.

Sputtering is a physical vapor deposition (PVD) process which involves bombarding the surface of the coating material (target) with gas ions under high voltage acceleration, in order to promote the ejection of atoms from the target. The ejected atoms will be propelled towards the substrate, forming a thin-film coating over its surface. Plasma Enhanced PVD, like magnetron sputtering, is considered to be the most efficient technology. For this process an inert gas is required: Argon is the most commonly used, however some sputtering processes may involve oxide or nitride film coatings; if so O2 and/or N2 are added to the inert sputtering gas. According to its nature, the process requires low pressures nevertheless the process gas flow must be sufficient for allowing the ionic bombardment process to take place, otherwise it becomes impossible to maintain the plasma. Hence, the process gas flow must be meticulously controlled, if not, the quality and optimal homogeneity of the coating may be severely compromised.

Due to its unique proportional electromagnetic control valve, Bronkhorst High-Tech mass flow controllers are ideal for this application. The instruments allow simultaneously an extremely fast and smooth control, providing excellent stability and repeatability.
